| Parc | repository.equipment.context_wreck |
| Reference | 19672 |
| Make | Yale |
| Model | MP20X |
| Hours | 3 486 h |
| Power | Electric |
| Lifting capacity | 2 000 Kg |
| Type of tyre | Railway tyre |
| Fleet number | 1784 - M7753 |
| Type | Folding platform |
| Fork length | 1 183 mm |
| Length | 2368 mm |
| Width | 780 mm |
| Weight | 862 Kg |
| Overall height lowered mast | 1460 mm |
| Free lift (h2) | 220 mm |
| Warranty |
parts guaranteed 3 months |
Transpalette plate forme rabattable , mode conducteur debout ou accompagnant
Capacité nominale 2000Kg cdg 600mm
Variateur Combi Mosfet
Technologie à courant alternatif AC technology
Fourches 1150x560mm
hauteur des fourches 85mm
Longueur L2 enj mode plate forme 1225mm
Bandages vulkollan 1 roue motrice, 2 roues stabilisatrices
Galets de fourches tandem
course d'elevation 130mm
Traction motor ac 4 kW
Hoist motor ac 1.4 kW
Travel speed with / without load 8.5/12 km/h
Hoisting with / without load 0.03 m/s
Lowering with load 0.04/0.03 m/s
max. climbing ability10/20 %
Rayon de giration wa 2230mm
Ast palette 1200x800mm
Freinage électromagnétique
